Thermostats

Floor Heating Thermostats provide safety and flexibility for your radiant floor heating installation. We have several options providing different features, look and feel. Most important though is Safety; we only offer Thermostats that have built-in GFCI safety protection, unlike other companies.

Why a Thermostat? While some people have connected a floor heating system to a simple switch, it would not be safe and would not meet building codes or safety standards. Thermostats for floor heating have a sensor within the floor to accurately measure the temperature. This floor sensor comes with the thermostat and is installed when you install the floor heating system.

Programmable thermostats are our number one sellers and have a clock and 7 day calendar built-in which allowa you to set the time and temperature options according to your schedule. You floor will automatically turn on and off at the times you choose and to the temperature you prefer. You can set your own program, or use one of the standard schedules already preset in the Stat. Having your floor off when you are away from home also saves you money, just like turning off the lights when you aren’t home. Of course, all programmable models also can be simply turned off or put into a manual non programmable mode too.

Programmable Thermostats are Best for:

  • Energy savings – never forget to turn it off (or on)
  • Warm floors when you want them – pre-heated according to your daily schedule
  • Set it and forget it – same schedule every day or a different one for weekends
  • Still allow the flexibility of manual override control to change temperature or on/off

Non Programmable thermostats give you complete manual control over your floor temperature but have no clock or timer features. Choose a simple dial or an LCD screen with buttons and backlight. On/Off, GFCI test, and temperature setting are your only options. The floor will continually warm to the temperature you set until you change the temperature or turn it off.

Remember, floor heating doesn’t come to temperature instantly like turning on a light switch. The floor heating has to warm up the mortar and tile and can take anywhere from 15 min (insulated frame floor above a heated space) to a few hours on concrete slabs.

Non Programmable models are best for:

  • Small areas that you may leave on all winter or low energy cost areas
  • Those wanting simplicity and frequent changing schedules
  • Framed floors – not on concrete
  • Patient people

Any of our thermostats will work with any of our floor heating systems interchangeably. All models have floor sensing capability and include a floor sensor wire. Some thermostats have Ambient Air temperature modes and floor limit features. See individual models for a listing of all features.

Looking for help with your existing thermostat?

Click here for thermostat manuals and support!
Set Descending Direction
view all

10 Result(s) found

Thermostat Manuals & Support

Click on a link or Scroll down to see pictures of all Thermostats



SunTouch SunStat Current Production Models

SunTouch Previous Models (no longer in Production)

Nuheat Thermostat Current Production Models

Nuheat Previous Models (no longer in Production)



SunTouch SunStat Current Production Models

  • Manufactured by SunTouch's parent company Watts Radiant.
  • The thermostats can have different letters after the model number and refer to packaging or market area; but all are the same in function, features and look
  • All SunTouch Thermostats are in 2 pieces - the “power base” which mounts to the wall, and the “Faceplate” which mounts to the power base. These items are not interchangeable and are not sold separately. If you ever need to replace or return a thermostat, you need to replace both pieces – never just change the faceplate.

SunStat PRO (programmable) 500670 (500670 -SC , -BB, -HW, -BW, etc)

SunStat Virtual thermostat interactive tutorial

^ Back to top

SunStat (non-programmable) 500675 (500675 -SC , -BB, -HW, -BW, etc)

SunStat Relay 500680

^ Back to top

SunStat Dial 500710 (non-programmable)

^ Back to top





SunTouch Previous Models

no longer in production (most recent to oldest)



SunTouch FloorStat



SunTouch FloorStat 500650

120-VAC Models: 500650-120CS, -120B, -120BH, and -120BW & 240-VAC Models: 500650-240CS and -240B)

Each Side of the thermostat has a door that open to reveal programming buttons.

Need a new one? The direct replacement Model for all FloorStats is : SunStat PRO – click here. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit from the wall and then replace with this new unit. Same box, same hole – just swap them out.

The above 3rd generation FloorStats had the GFCI Test Button & Light on TOP of the thermostat (as shown in the diagram)

FloorStat 2nd generation, below had the GFCI test Light concealed behind the LEFT door, just under the ON/STANDBY switch – see below.

FloorStat 500650 – 1st generation – No Backlight, but other operations the same.

Need a new one? The direct replacement Model is : click here. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit from the wall and then replace with this new unit. Same box, same whole, same wiring – just swap them out.

^ Back to top

FloorStat 500600 – The first programmable FloorStat

Need a new one? The direct replacement Model is : click here. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit from the wall and then replace with this new unit. Same box, same whole, same wiring – just swap them out.

FloorStat 500500

was the first FloorStat and was often used in conjunction with an intermatic timer to provide some time/date functions.

^ Back to top

SunStat 500700-120 Dial Control

Need a new one? The direct replacement for the 500700 Model is : SunStat 500710 Dial – click here. Or Upgrade to the SunStat or the SunStat PRO. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit from the wall and then replace with this new unit. Same box, same hole – just swap them out.

^ Back to top

FloorStat 500550-120 Dial Control

was discontinued in 2009, but there is limited remaining stock and will be sold until inventory is depleted.

Need a new one? The direct replacement Model is : SunStat 500710 Dial – click here.Or Upgrade to the SunStat or the SunStat PRO. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit from the wall and then replace with this new unit. Same box, same whole, same wiring – just swap them out.

^ Back to top

SunTouch GroupStat

The First Generation Master/Relay Controls. Relay has a door that Slides “up” to reveal On/Off switch and GFCI test

These controls have been discontinued and replaced by the SunStat PRO & SunStat Relay.

BUT, a Relay CANNOT be replaced with the New SunStat Relay unless the MASTER unit is also replaced by the SunStat PRO.

^ Back to top





Nuheat Thermostat Current Production Models

  • Manufactured exclusively for Nuheat.
  • The SOLO and Tempo Thermostats are in 2 pieces – the “power base” which mounts to the wall, and the “Faceplate” which mounts to the power base. These items are not interchangeable and are not sold separately. If you ever need to replace or return a thermostat, you need to replace both pieces – never just change the faceplate.

SOLO

^ Back to top

Tempo (non-programmable)

^ Back to top

Harmony DV

^ Back to top



Nuheat Previous Models

no longer in production (most recent to oldest)

Need a new one? The direct replacement Model for all Nuheat Programmable Stats is the Nuheat Solo – click here. Use the sensor that is already installed in the floor, simply turn power off at breaker and have qualified installer remove the entire unit (not just the front face plate) from the wall and then replace with this complete new unit. Same box, same hole, same sensor – just swap them out.

Nuheat NTG-5110(110v) / NTG 5220(220v)

Each Side of the thermostat has a door that open to reveal programming buttons.

The above 2nd generation NTG-series had the GFCI Test Button & Light on TOP of the thermostat (as shown in the diagram)

NTG-series 1st generation, below had the GFCI test Light concealed behind the LEFT door, just under the ON/STANDBY switch – see below.

^ Back to top

Nuheat FTGF1P (110v) / FTGF2P (220v) – The first programmable Nuheat T-stat

^ Back to top

Nuheat Regulator NDG6110/NDG6220

Non-programmable Dial control – No floor sensor was used.

Need a new one? The replacement Model for the Nuheat Regulator is the Nuheat Tempo – click here. Turn power off at breaker and have qualified installer remove the entire unit (not just the front face plate) from the wall and then replace with this complete new unit. Same box &same hole.

If you want to add the accuracy and convenience of a floor sensor (included with the TEMPO but wasn't used with NDG) you can install the sensor in the floor – very carefully in a grout joint or from below; but don't damage your mat.

The easier solution is to set the Tempo to A mode; in “A” mode, the thermostat controls the ambient air temperature. This setting is useful if the floor temperature sensor is not installed.

^ Back to top
