SunStat R4 Relay Wired connection extends system above 15 amps (Wireless option w/ ConnectPLUS only)
-
We keep lots of stock on hand, which means we have what you need to ship today. And depending on when you order and where you need it shipped, it could take as little as 1 day to get it to you. Custom mats, built to order take 3-5 days to produce.
For Free Shipping over $149, simply choose the Free Shipping option during checkout, no coupon needed. Free Shipping only applies to standard ground shipping for the 48 contiguous US States and excludes oversized items. See Details -
If you find a lower price from an authorized reseller in the USA, we will do our best to match it. Email us a link to the identical, new, in-stock product. OR call us (1-866-558-3369) and we'll confirm the price on the phone. Free shipping and other promotions are taken into consideration as part of the total price. See Details
-
M-F 6:30am - 5pm PST, 1 866 558 3369
Highlights
Safe
UL approved 15 Amp Class A GFCI protection built-in for 120v & 240v
Warranty
3 Year Manufacturer Warranty
Description
Each R4 Relay requires its own circuit breaker and provides additional capacity for spaces that are larger than a SunStat® thermostat can control on its own. The R4 Relay energizes the connected mat or cable any time the thermostat determines that heat is required. When the thermostat signals the relay to operate, the Heating Indicator is illuminated. Each R4 Relay requires an additional 20-amp circuit and individual circuit breaker to operate.
The SunStat® R4 Relay is designed to control the voltage to SunTouch® electric floor heating systems that require more than 15 amps. Up to 10 (wired) SunStat Relays may be connected to one SunStat Thermostat for 120 VAC systems as large as 1650 Sq Ft or 240 VAC systems as large as 3300 Sq Ft .
The first circuit should be the thermostat, which can be fully loaded with Floor heating, then additional mats or cables can be connected to each subsequent relay required.
The thermostat is connected to the first Relay 4 via a low-voltage wire or a wireless connection (not Wi-Fi for compatible T-stats only), and additional Relays can be daisy-chained to the next relay using additional runs of wire or wireless functionality. New Wireless technology using 915 MHz (similar to BlueTooth, but not Wi-Fi) allows control (by ConnectPLUS only, or it can be wired with a low voltage wire to the ConnectPLUS or certain older thermostats.
Features and Benefits:
• Extends the Area Controlled by a SunStat ConnectPlus Thermostat
• Wired Connection to CommandPlus 500950, Command 500850, Core 500825 and Connect model 500875. Can replace an existing R3 relay also
• Wired or wireless connection to the ConnectPLUS thermostat 500900
• Up to 10 wired R4 Relays per thermostat (up to 300 SF each)
• Up to 6 wireless R4 Relays per thermostat (ConnectPLUS only)
• Wireless R4 Relays report energy usage to the thermostat
• Built-in Class A GFCI test light and button with a 5-milliamp trip for safety
• Dual-voltage 120/240 VAC 60 Hz, 1800/3600 W max resistive load, 15 Amp max load
• LED Status indicator lights for power, heating, GFCI test/trip modes, and troubleshooting
• 3-year manufacturer warranty
• Ambient conditions 32°F to 86°F (0°C to 30°C) < 90% RH non-condensing
• R4 wireless connection see Operation > Wireless Pairing
• R4 Wiring to thermostat Pull 18 - 24 AWG 2-conductor wire from the thermostat to the R4 Relay location, up to 100 ft (30 m) long
Resources
Indoor mount only
Pull power supply wiring to the Relay location.
-
Leave about 6 to 8" (15 to 20 cm) of wire for connections.
-
This wiring should be size 12 or 14 AWG, in compliance with local code requirements.
-
A qualified person should run a dedicated circuit (ideal) from the main circuit breaker panel to the control location. If a dedicated circuit is not possible, it is acceptable to tap into an existing circuit. However, there must be enough capacity to handle the load (amps) of the floor heating system being installed, and any appliance likely to be used on the circuit such as a hairdryer or vacuum cleaner.
-
Always avoid circuits that have ballasted lighting, motors, exhaust fans, or hot tub pumps to reduce the likelihood of interference.
-
The circuit breaker should be rated 20 amps for total circuit loads up to 15 amps. A 15-amp circuit breaker may be used for total circuit loads up to 12 amps.
-
A GFCI (ground-fault circuit interrupter) or AFCI (arc-fault circuit interrupter) type circuit breaker may be used, but is not necessary.
Materials Required
-
Electrical box (must be UL listed and proper size)
-
Vertical 1-gang box (For multiple heating elements use a 2-gang (4x4) box with single-gang mud ring)
-
-
Conduit, flexible or rigid (if required, must be UL listed and proper size)
-
Electrical wiring cable (UL listed)
-
Minimum 14 AWG to 12 A / 12 AWG to 15 A
Specifications
Size in Inches 4.73" H x 3.11" W x 1.9" D (120 x 79 x 48 mm)
GFCI / GFEP Protection 5 mA Class A Built In - With Test Button Feature & indicator light
Inside Box Depth 1.28 inches
Inside Box Width 1 11/16" (42.9 mm)
More Details
What's In The Box Relay, Instructions
UPC 840213021542
Warranty from Manufacturer 3 yr
Manufacturer Watts Radiant
Safety Listing Safety Listed in USA & Canada : UL 943, UL/CSA 60730, UL 991
Programming Method None - Controlled by Thermostat
Thermostat Type Relay
